GT5

Name: Elan Yachts GT5
Brand: Elan Yachts
Price: 467900 EUR

Cruising yachtsGran Turismo rangeIn production

Elan Yachts GT5: Couple having lunch on a boat

Hull length12.41 mFilter by hull length

Beam3.91 m

Draught2.44 m

Weight8,970 kgFilter by weight

Max. power114 hp

CE categoryA

About this boat

The Elan GT5 is the smallest model in the GT range, with a hull length of 12.41 metres and an overall length of 13.20 metres. The GT range combines the sailing characteristics of the E-range with greater comfort below deck. The waterline length is 11.58 metres, with a beam of 3.91 metres.

Specifications

Dimensions and weight

Hull length: 12.41 m
Length overall: 13.20 m
Beam: 3.91 m
Draught: 2.44 m
Air draft: 18.39 m
Weight: 8,970 kg
Max. persons: 10

Engine

Max. power: 114 hp
Number of engines: 2
Max. power per engine: 57 hp
Fuel tank: 146 l

Hull and construction

CE category: A
Hull material: GRP

Accommodation

Berths: 8

Full description

Show full description

The standard keel has a draught of 2.25 metres; there is also a 2.45-metre keel and a shallow-draught version of 1.95 metres. The light weight is 8,970 kilograms with 2,655 kilograms of ballast. The yard offers four interior layouts.

The standard engine is a Yanmar 4JH45 producing 33.1 kW (45 hp), with an optional Yanmar 4JH57 producing 41.9 kW (57 hp). In addition, there is a 15 kW Oceanvolt electric drive or a twin 10 kW unit. The fuel tank holds 146 litres and the water tank 220 litres, which can be expanded to 490 litres.

The sail plan consists of a mainsail measuring 46.2 square metres and a jib measuring 32.7 square metres, with an asymmetrical spinnaker measuring 130 square metres available as an option. The air draft is 18.39 metres.

The boat is classified as CE design category A.
