Power6 hpFilter by power
Weight28 kg
Shaft lengthShort shaft, long shaft
StartManual start
Fuel tankIntegrated, 1,5 l
SteeringTiller
Specifications
- Power
- 6 hp
- Power (kW)
- 4.4 kW
- Cylinders
- 1
- Displacement
- 127 cc
- Weight
- 28 kg
- Dimensions (l × w × h)
- 524 × 347 × 1,020 mm
- Rated rpm
- 6,000 rpm
- Shaft length
- Short shaft, long shaft
- Start
- Manual start
- Fuel tank
- Integrated, 1,5 l
- Steering
- Tiller
- Trim/tilt
- Manual tilt
- Fuel
- Petrol
- Mounting
- Outboard
Boats with this engine
Boats on which the Honda BF 6 is available as standard or as an option, as stated by the builder.
Explainer
Which shaft length do I need?
The shaft length must match the transom height of your boat: the height of the transom, measured from the top to the bottom of the hull.
- 1
Measure your transom
Measure the transom height in the middle of the transom, straight down to the bottom of the hull.
- 2
Compare with the engine
For each shaft length the manufacturer states which transom height it is meant for. Choose the shaft that matches.
- 3
Too short or too long?
Too short: the propeller draws in air and cooling works poorly. Too long: more drag and less speed. In doubt, ask the builder or a dealer.
